WatchGas SST1 Pink – Safety with a Purpose
The WatchGas SST1 Pink is a compact single-gas detector engineered to protect workers in challenging environments. Designed for simplicity, durability, and reliability, SST1 Pink delivers dependable personal gas detection for a wide range of industrial applications.
- Available in maintenance-free (up to 3 years) and serviceable models
- NFC capability
- High audible alarm, 95dB @30cm
- Cost-effective
- Extremely stable and reliable sensors
- Largest LCD display
Description
The SST1 Pink single-gas detector is the same trusted SST1, now available in a distinctive pink color to support breast cancer awareness initiatives. Designed for ultimate simplicity, durability, and cost-effective protection, the SST1 Pink range is available in maintenance-free models with up to three years of operation, as well as serviceable models to suit different operational requirements.
Available in a wide range of single-gas configurations, including H₂S, CO, O₂, and SO₂, the SST1 Pink provides reliable protection in a simple, easy-to-use design. Its intuitive interface reduces training requirements, making it suitable for users of all experience levels.
When paired with the SST Dock, the SST1 Pink allows rapid bump testing and streamlined fleet management and compliance.
Product information
- Easy setup
- NFC
- 95dB @30cm
- Cost-effective
- Extremely stable and reliable sensor
- Largest LCD display
- Rugged
| Size | 83 × 49 × 20 mm (3.3 × 1.9 × 0.8 in) |
| Weight | 88 g (3.1 oz) |
| Temperature | -40 to +140°F /-40 to +60°C |
| Humidity | 5 - 95 % RH |
| Battery life | H2S, CO, O2, SO2: 2 years depending on the version |
| Event logging | Last 100 events |
| IP | IP67-68 |
| Communication | NFC |
| Shelf life | 1 year |
| Certifications & Approvals | ATEX, IECEX, UKEX II 1 G Ex ia IIC T4 Ga I M1 Ex ia I Ma 0344 Int.Safe: Cl I Dv 1, Gr A,B,C,D T4 CSA C22.2 NO. 60079-0 CAN/CSA C22.2 NO 60079 UL 61010 safety requirements CAN/CSA-C22.2 NO 61010-1-12 Low Voltage Directive 2014/35/EU EMC Directive 2014/30/EU |
| Warranty | One year shelf life then two or three years from activation date depending on device type |
| Sensor | Gas measuring range | Low alarm level | High alarm level |
| H2S | 0 - 500 ppm | 10 ppm | 15 ppm |
| CO | 0 - 2000 ppm | 35 ppm | 200 ppm |
| O2 | 0 - 25.0% by vol. | 19.5 % | 23.5 % |
| SO2 | 0 - 100 ppm, | 5 ppm | 10 ppm |
| * Factory alarm set points can be changed via WatchGas Application |
SST1: 2 and 3 year fixed life single gas device
SST1-H-24-P – WatchGas SST1 H2S 0-500ppm 2-year fixed life Pink (hydrogen sulphide)
SST1-M-24-P – WatchGas SST1 CO 0-2000ppm 2-year fixed life Pink (carbon monoxide)
SST1-O-24-P – WatchGas SST1 O2 0-25%vol. 2-year fixed life Pink (oxygen)
SST1-S-24-P – WatchGas SST1 SO2 0-100ppm 2-year fixed life Pink (sulfur dioxide)
SST1-H-36-P – WatchGas SST1 H2S 0-500ppm 3-year fixed life Pink (hydrogen sulphide)
SST1-M-36-P – WatchGas SST1 CO 0-2000ppm 3-year fixed life Pink (carbon monoxide)
SST1 Serviceable: Single gas device with TWA and STEL option
SST1-H – WatchGas SST1 H2S 0-500ppm Serviceable – Real Time Display (Hydrogen Sulfide)
SST1-M – WatchGas SST1 CO 0-2000 ppm Serviceable – Real Time Display (Carbon Monoxide)
SST1-O – WatchGas SST1 O2 0-25%vol. Serviceable – Real Time Display (Oxygen)
SST1-S – WatchGas SST1 SO2 0-100ppm Serviceable – Real Time Display (Sulfur Dioxide)
SST1-A – WatchGas SST1 NH3 0-100ppm Serviceable (Ammonia)
SST1-P – WatchGas SST1 PH3 0-20ppm Serviceable (Phosphine)
SST1-H2 – WatchGas SST1 H2 0-1000ppm Serviceable (Hydrogen)
SST1-H2HR – WatchGas SST1 H2 0-20,000ppm High Serviceable (Hydrogen)
SST1-MM – WatchGas SST1 CH4S 0-100ppm Serviceable (Methanethiol AKA Methyl Mercaptan)
Please contact WatchGas or your local WatchGas distributor for the order information on accessories and spare parts.
|
